Treatment table Background technology:

Rehabilitation treatment bed is a kind of auxiliary medical equipment to restore and exercise the physical functions of disabled people. Some functions of rehabilitation treatment bed are used to exercise patients and make them recover their physical functions slowly.

Rehabilitation treatment bed, on the market at present is not only single varieties, and complex structure, adjustable elastic broadband, not upper limb function training, not set feet fixed clamp, cannot undertake sit-ups training, not set electric telescopic column, unable to control the bed height, not set massager, will not waist massage on the sick.

Treatment table Technical implementation elements:

The utility model aims to provide a rehabilitation treatment bed, in order to solve the above technical background in the telescopic elastic broadband, not upper limb function training, not set feet fixed clamp, cannot undertake sit-ups training, not set electric telescopic column, unable to control the bed height, not set massager, will not waist massage on the sick.

In order to solve the above technical problems, the utility model provides the following technical solutions:A rehabilitation treatment bed, bed board, massager, TAB, telescopic elastic broadband, the first fixture, slippery course, wool layer, electric telescopic column, base, electric cabinet, fixed with thick plate, the positive disk, the second fixture, negative disk, slider, card buckle, chute, rod and spring, and the lower end of the bed board Settings are described and fixed with thick plate, and the top of the bed board installed in central massager, described in the setting of the top end of the bed board has a first fixture, as described in the lower end of the fixed with thick plate fitted with electric telescopic column, as described in the lower end of the electric telescopic column set base, described the first fixture on one side of the installation is a slippery course,The first fixture and the inside of the set have wool layer, described massager are set on both sides of the telescopic elastic broadband, described at the end of the telescopic elastic broadband connection TAB, as described in the first fixture is installed in one side of the anode discs, described the second clamp the cathode is set in one side of the disk, as described in the other end of the telescopic elastic broadband installation card buckle, described card buckle in the middle of the set has a chute, described in the chute set inside the slider, described the slider set the card at the end of the rod, and the other end of the slider set with spring.

Further, the massager is composed of an iron core (including a fixed iron core and a movable iron core), a coil, a vibrating spring piece and a massage head.

Furthermore, the massager and the electric telescopic column are electrically connected with the electric control box, and the massager, the electric telescopic column and the electric control box are electrically connected with the external power supply.
